H₂O₂ Capsule Type Hydrogen Peroxide Plasma Sterilizer | Low-Temperature Medical & Lab Sterilization Equipment

1️⃣ Product Overview: High-Performance H₂O₂ Plasma Sterilization

    The Sada Medical 130L Hydrogen Peroxide Plasma Sterilizer (Model: SD-WD) is a cutting-edge low-temperature sterilization system designed for hospitals, dental clinics, laboratories, and research institutions. Using hydrogen peroxide (H₂O₂) gas plasma technology, it provides a fast, safe, and effective sterilization process for heat-sensitive and moisture-sensitive instruments.

🔹 Fast sterilization cycle (30-50 minutes) – Ideal for rapid instrument turnaround.
🔹 Low-temperature sterilization (45-55°C) – Prevents heat damage to delicate materials.
🔹 Eco-friendly & residue-free – No toxic emissions, ensuring a safe working environment.
🔹 No external water or ventilation required – Easy installation, minimal maintenance.

    Designed for Central Sterile Supply Departments , operating rooms , and research labs, ensuring infection control and patient safety.

---

2️⃣ Key Features & Advantages

Ultra-Fast & Efficient Sterilization

• Short sterilization cycles – Choose from 30, 50, or 60 minutes for optimized instrument processing.
• High penetration vacuum technology – Ensures complete sterilization of hollow and complex instruments.

 Low-Temperature Sterilization (45-55°C)

• Ideal for heat-sensitive instruments – Safe for plastics, optics, and delicate surgical tools.
• Prevents material degradation – Unlike steam autoclaves, it does not damage fragile materials.

Superior Safety & Compliance

• Meets international sterilization standards – ISO 9001, ISO 13485, EN 14937, EN 61010.
• Advanced Siemens PLC control system – Ensures precision and automation.
• Automatic safety features – Door lock system, temperature monitoring, vacuum testing, and pressure regulation.

Smart & User-Friendly Design

• 7” LCD Touchscreen Display – Easy operation with real-time monitoring.
• Built-in printer – Automatically records sterilization cycles for regulatory compliance.
• Automatic lift door – Hands-free operation for enhanced hygiene and safety.
• Compact & portable with caster wheels – Easy mobility within hospitals and labs.

---

3️⃣ Technical Specifications

Model	SD-WD100	SD-WD135	SD-WD190
Chamber Volume	100L	135L	190L
Material	5052 Aluminum	5052 Aluminum	5052 Aluminum
Processing Temperature	Below 55°C	Below 55°C	Below 55°C
Control System	Siemens PLC	Siemens PLC	Siemens PLC
Display	7” Touchscreen	7” Touchscreen	7” Touchscreen
Printer	Ribbon & Thermal Printer	Ribbon & Thermal Printer	Ribbon & Thermal Printer
Data Storage	Memory Card	Memory Card	Memory Card
Cycle Time	30/50/60 mins	30/50/60 mins	30/50/60 mins
Noise Level	<60 dB	<60 dB	<60 dB
Door Type	Automatic Lift Door	Automatic Lift Door	Automatic Lift Door
Alarm System	Door Lock, Power Failure, Temp Range, Vacuum & Pressure	Door Lock, Power Failure, Temp Range, Vacuum & Pressure	Door Lock, Power Failure, Temp Range, Vacuum & Pressure
Peripheral Devices	Biological Incubator	Biological Incubator	Biological Incubator
Power Consumption	3.4 KVA	3.5 KVA	4.3 KVA
Power Supply	AC (220±22)V, (50±1)Hz	AC (220±22)V, (50±1)Hz	AC (220±22)V, (50±1)Hz
Mobility	4 Wheels	4 Wheels	4 Wheels
Compliance	ISO 9001, ISO 13485, EN 14937, EN 61010	ISO 9001, ISO 13485, EN 14937, EN 61010	ISO 9001, ISO 13485, EN 14937, EN 61010

---

4️⃣ Application Scenarios

Ideal for Various Medical & Laboratory Environments

🔹 Hospitals & Operating Rooms – Ensures the sterility of surgical tools, endoscopes, and other delicate medical devices.
🔹 Central Sterile Supply Departments – Improves sterilization workflow efficienc

🔹 Dental Clinics – Safe for sterilizing dental instruments, reducing cross-infection risks.
🔹 Laboratories & Research Institutions – Suitable for sterilizing biological dressings, glassware, and scientific equipment.
🔹 Pharmaceutical & Biotechnology Facilities – Ensures contamination-free environments for sensitive production processes.

    The perfect sterilization solution for medical professionals seeking efficiency, safety, and compliance.
